Controller Fanuc

Travel
X / Y / Z travel: 2,000/1,800/1,700 (78.7/70.8/66.9 Inch) mm
W axis travel: 500 (19.6 Inch) mm
Table
Table size: 1,400×1,600 (55.1×62.9 Inch) mm
Max. table load: 8,500 Kgs
Min. B axis index: 0.001 degree
Spindle center to table surface: 0 ~ 1,800 mm
Spindle
Speed: 5~2,500 rpm
Taper: ISO NO 50
Spindle diameter ( W axis ): Ø110 mm
Automatic Tool Changer
Tool storage capacity: 40 pcs (*60pcs)
Three axis D.R.O. Heidenhain
Y axis balance equipment Hydraulic Counter Weight System
